P3 MODULAR

Specifications

LED Wall Module Size(mm): 192*192*15

Weight: 300g

Power Requirements: 220V-250V 50-60Hz

Power Consumption: 195/580W

Pitch: P3 16S(Indoor Series)

Brightness: >2200 nit

Lamp: MSD 2121 Black Series

Red: 110-150mcd(620-623nm)

Green: 300-500mcd(517-529nm)

Blue: 100-200mcd(470-473nm)

Refreshing Rates: >25200 Hz

Grey Level: 14-16 bit

Viewing Angle: 120 degrees *120p degrees

IP Rate: IP31

Manufactured in: Shenzhen

Designed By: Clair Illumination

P3.91 MODULAR

Specifications

LED Wall Module Size(mm): 250*250*15

Weight: 0.5kg

Power Requirements: 220V-250V 50-60Hz

Power Consumption: 195/580W

Pitch: P3.91  16S (Indoor Series)

Brightness: >2200 nit

Lamp: MSD 2121 Black Series

Red: 110-150mcd(620-623nm)

Green: 300-500mcd(517-529nm)

Blue: 100-200mcd(470-473nm)

Refreshing Rates: >25200 Hz

Grey Level: 14-16 bit

Viewing Angle: 120 degrees *120 degrees

IP Rate: IP31

Manufactured in: Shenzhen

Designed By: Clair Illumination

P3.91 RENTAL SET

Specifications

Model: RP391SL

LED Wall Cabinet Size(mm): 500*500* 70

Weight: 6kg

Power Requirements: 220V-250V 50-60Hz

Power Consumption: 195/580W

Pitch: P3.91  16S (Indoor Series)

Brightness: >2200 nit

Receiving Card: Nova Star MSD 300

Lamp: MSD 2121 Black Series

Red: 110-150mcd(620-623nm)

Green: 300-500mcd(517-529nm)

Blue: 100-200mcd(470-473nm)

Refreshing Rates: >25200 Hz

Grey Level: 14-16 bit

Viewing Angle: 120 degrees *120 degrees

IP Rate: IP31

Power Input Connection: Powercon In/Out

Signal Input Connection: XLR LAN Cable In/Out

Locking System: Quick Release Fast Locking Omega System

Manufactured in: Shenzhen

Designed By: Clair Illumination

P4 MODULAR

Specifications

LED Wall Module Size(mm): 256*192*15

Weight: 200g

Power Requirements: 220V-250V 50-60Hz

Power Consumption: 195/580W

Pitch: P4  16S (Indoor Series)

Brightness: >2200 nit

Lamp: MSD 2121 Black Series

Red: 110-150mcd(620-623nm)

Green: 300-500mcd(517-529nm)

Blue: 100-200mcd(470-473nm)

Refreshing Rates: >25200 Hz

Grey Level: 14-16 bit

Viewing Angle: 120 degrees *120 degrees

IP Rate: IP31

Manufactured in: Shenzhen

Designed By: Clair Illumination

P4 RENTAL SET

Specifications

Model: RP391SL

LED Wall Cabinet Size(mm): 512*512*85

Weight: 9kg

Power Requirements: 220V-250V 50-60Hz

Power Consumption: 195/580W

Pitch: P4  16S (Indoor Series)

Brightness: >2200 nit

Receiving Card: Nova Star Receiving Card

Lamp: MSD 2121 Black Series

Red: 110-150mcd(620-623nm)

Green: 300-500mcd(517-529nm)

Blue: 100-200mcd(470-473nm)

Refreshing Rates: >25200 Hz

Grey Level: 14-16 bit

Viewing Angle: 120 degrees *120 degrees

IP Rate: IP31

Power Input Connection: Powercon In/Out

Signal Input Connection: XLR LAN Cable In/Out

Locking System: Quick Release Fast Locking Omega System

Manufactured in: Shenzhen

Designed By: Clair Illumination
